Toyota Enclosed End Rider Pallet Jack

Toyota Enclosed End Rider Pallet Jack

Efficiently delivering pallets throughout the warehouse, Toyota’s Enclosed End River won’t let you down. Because it’s a Toyota, you get legendary quality and durability you expect to increase your uptime.

  • 6,000-8,000 lb. Load Capacity
  • Programmable Lift Capability
  • Reinforced Steel Ductile Iron Undercarriage
  • Auto Slow Down
  • Universal Tapered Forks Option
STANDARD FEATURES
  • Cushioned Hip and Knee Pads
  • Multifuntional Control Handle
  • 24 Volt Battery
  • AC Drive Motor
DESCRIPTION

The Toyota Enclosed End Rider Pallet Jack makes traveling through your warehouse while
loading and unloading products simple and easy. This Enclosed End Rider is the pallet-moving secret to productivity, efficiency, and uptime that you’ve been looking for. Designed with a steel-enforced undercarriage and stainless pins for reinforced strength to handle the heaviest of loads, the Enclosed End Rider is the perfect lift for delivering an impeccable performance so you can get the job done.

► LIFT HEIGHT TRAVEL INTERLOCK is a training tool to encourage operators to drive with the forks lifted by limiting travel speed when forks are lowered

► ELECTRIC POWER STEERING decreases the amount of effort required to steer, increasing the operator’s comfort. Auto steering automatically centers the steer tire on startup

► UNIVERSAL TAPERED FORKS OPTION makes pallet exit and entry easier

► COLD STORAGE OPTION protects components from condensation and cold temperatures

► AC DRIVE MOTOR for better acceleration, quiet operation, and overall smoothness of travel

► REINFORCED STEEL DUCTILE IRON UNDERCARRIAGE adds strength throughout the underside of the unit for added rigidity

► LIFT AND LOWER BUTTONS give operators precise lift and lower control

► 10” LOW STEP HEIGHT creates ease for operators when stepping on or off the floorspace

► AUTO SLOW DOWN occurs when turning a corner making it easier to transport large loads when cornering

► SIDESTANCE POSITION enables operators to easily change direction and travel long runs shuttling pallets from dock to stock or vice versa



MODEL CAPACITY* MAX TRAVEL SPEED FULL LOAD (MPH) MAX LIFT SPEED FULL LOAD (FPM) MAX GRADEABILITY FULL LOAD (%) BASIC RIGHT ANGLE STACK**
ER1-ES60
6,000 lbs.
6.2
N/A
8
80.7-184.4
ER1-ES80
8,000 lbs.
6.5
N/A
8
80.7-184.4

*Based on 24” load center. **Add load length and clearance
